#General Specifications |
#Platform |
#Desktop |
#Market Segment |
#Enthusiast Desktop |
#Product Family |
#AMD Ryzenâ„¢ Processors |
#Product Line |
#AMD Ryzenâ„¢ 5 Desktop Processors |
#AMD PRO Technologies |
#No |
#Consumer Use |
#Yes |
#Regional Availability |
#Global |
#Former Codename |
#Raphael AM5 |
#Architecture |
#Zen 4 |
#of CPU Cores |
#6 |
#Multithreading (SMT) |
#Yes |
#of Threads |
#12 |
#Max. Boost Clock |
#Up to 5.3GHz |
#Base Clock |
#4.7GHz |
#L1 Cache |
#384KB |
#L2 Cache |
#6MB |
#L3 Cache |
#32MB |
#Default TDP |
#105W |
#Processor Technology for CPU Cores |
#TSMC 5nm FinFET |
#Processor Technology for I/O Die |
#TSMC 6nm FinFET |
#CPU Compute Die (CCD) Size |
#71mm² |
#I/O Die (IOD) Size |
#122mm² |
#Package Die Count |
#2 |
#Unlocked for Overclocking |
#Yes |
#AMD EXPOâ„¢ Memory Overclocking Technology |
#Yes |
#Precision Boost Overdrive |
#Yes |
#Curve Optimizer Voltage Offsets |
#Yes |
#AMD Ryzenâ„¢ Master Support |
#Yes |
#CPU Socket |
#AM5 |
#Supporting Chipsets |
#X670E
#X670
#B650E
#B650 |
#CPU Boost Technology |
#Precision Boost 2 |
#Instruction Set |
#x86-64 |
#Supported Extensions |
#AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
#Thermal Solution (PIB) |
#Not included |
#Max. Operating Temperature (Tjmax) |
#95°C |
#OS Support |
#Windows 11 – 64-Bit Edition
#Windows 10 – 64-Bit Edition
#RHEL x86 64-Bit
#Ubuntu x86 64-Bit
#Operating System (OS) support will vary by manufacturer. |
#Connectivity |
#USB Type-C® Support |
#Yes |
#Native USB 3.2 Gen 2 (10Gbps) Ports |
#4 |
#Native USB 3.2 Gen 1 (5Gbps) Ports |
#0 |
#Native USB 2.0 (480Mbps) Ports |
#1 |
#Native SATA Ports |
#0 |
#Native PCIe® Lanes (Total/Usable) |
#28/24 |
#Additional Usable PCIe Lanes from Motherboard |
#AMD X670EÂ 12x Gen4
#AMD X670Â 12x Gen4
#AMD B650EÂ 8x Gen4
#AMD B650Â 8x Gen4 |
#NVMe Support |
#Boot, RAID0, RAID1, RAID10 |
#Memory Channels |
#2 |
#Max. Memory |
#128GB |
#System Memory Subtype |
#UDIMM |
#Max Memory Speed |
#1x1RÂ 5200 MT/s |
#ECC Support |
#Yes (Requires mobo support) |
#Graphics Capabilities |
#Integrated Graphics |
#Yes |
#Graphics Model |
#AMD Radeonâ„¢ Graphics |
#Graphics Core Count |
#2 |
#Graphics Frequency |
#2200 MHz |
#GPU Base |
#400 MHz |
#USB Type-C® DisplayPort™ Alternate Mode |
#Yes |
#Key Features |
#Supported Technologies |
#AMD EXPOâ„¢ Technology
#AMD Ryzenâ„¢ Technologies |
Warranty |
#3 Years |
Note: *** Features, Prices, and Specifications are subject to change without notice. |
