| #General Specifications |
| #Platform |
#Desktop |
| #Market Segment |
#Enthusiast Desktop |
| #Product Family |
#AMD Ryzen™ Processors |
| #Product Line |
#AMD Ryzen™ 9 Desktop Processors |
| #AMD PRO Technologies |
#No |
| #Consumer Use |
#Yes |
| #Regional Availability |
#Global |
| #Former Codename |
#Raphael AM5 |
| #Architecture |
#Zen 4 |
| # of CPU Cores |
#16 |
| #Multithreading (SMT) |
#Yes |
| # of Threads |
#32 |
| #Max. Boost Clock |
#Up to 5.7GHz |
| #Base Clock |
#4.5GHz |
| #L1 Cache |
#1MB |
| #L2 Cache |
#16MB |
| #L3 Cache |
#64MB |
| #Default TDP |
#170W |
| #Processor Technology for CPU Cores |
#TSMC 5nm FinFET |
| #Processor Technology for I/O Die |
#TSMC 6nm FinFET |
| #CPU Compute Die (CCD) Size |
#71mm² |
| #I/O Die (IOD) Size |
#122mm² |
| #Package Die Count |
#3 |
| #Unlocked for Overclocking |
#Yes |
| #AMD EXPO™ Memory Overclocking Technology |
#Yes |
| #Precision Boost Overdrive |
#Yes |
| #Curve Optimizer Voltage Offsets |
#Yes |
| #AMD Ryzen™ Master Support |
#Yes |
| #CPU Socket |
#AM5 |
| #Supporting Chipsets |
#A620
#X670E
#X670
#B650E
#B650 |
| #CPU Boost Technology |
#Precision Boost 2 |
| #Instruction Set |
#x86-64 |
| #Supported Extensions |
#AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| #Thermal Solution (PIB) |
#Not included |
| #Max. Operating Temperature (Tjmax) |
#95°C |
| #OS Support |
#Windows 11 – 64-Bit Edition
#Windows 10 – 64-Bit Edition
#RHEL x86 64-Bit
#Ubuntu x86 64-Bit
#Operating System (OS) support will vary by manufacturer |
| #Connectivity |
| #USB Type-C® Support |
#Yes |
| #Native USB 3.2 Gen 2 (10Gbps) Ports |
# 4 |
| #Native USB 3.2 Gen 1 (5Gbps) Ports |
#0 |
| #Native USB 2.0 (480Mbps) Ports |
#1 |
| #Native SATA Ports |
#0 |
| #PCI Express® Version |
#PCIe® 5.0 |
| #Native PCIe® Lanes (Total/Usable) |
#28/24 |
| #Additional Usable PCIe Lanes from Motherboard |
#AMD X670E 12x Gen4
#AMD X670 12x Gen4
#AMD B650E 8x Gen4
#AMD B650 8x Gen4 |
| #NVMe Support |
#Boot, RAID0, RAID1, RAID10 |
| #Memory Channels |
#2 |
| #Max. Memory |
#128GB |
| #System Memory Subtype |
#UDIMM |
| #Max Memory Speed |
#1x1R 5200 MT/s
#1x2R 5200 MT/s
#2x1R 3600 MT/s
#2x2R 3600 MT/s |
| #ECC Support |
#Yes (Requires mobo support) |
| #Graphics Capabilities |
| #Integrated Graphics |
#Yes |
| #Graphics Model |
#AMD Radeon™ Graphics |
| #Graphics Core Count |
#2 |
| #Graphics Frequency |
#2200 MHz |
| #USB Type-C® DisplayPort™ Alternate Mode |
#Yes |
| #Key Features |
| #Supported Technologies |
#AMD EXPO™ Technology
#AMD Ryzen™ Technologies |
| #Warranty |
#3 Years |
| Note: *** Features, Prices, and Specifications are subject to change without notice. |
