| #General Specifications |
| #Model |
#AMD Ryzen™ 5 8600G |
| #Platform |
#Desktop |
| #Product Family |
#AMD Ryzen™ Processors |
| #Product Line |
#AMD Ryzen™ 5 8000 G-Series Desktop Processors with Radeon™ Graphics |
| #AMD PRO Technologies |
#No |
| #Consumer Use |
#Yes |
| #Regional Availability |
#Global |
| #Former Codename |
#Phoenix |
| #Architecture |
#Zen 4 |
| #of CPU Cores |
#6 |
| #Multithreading (SMT) |
#Yes |
| #of Threads |
#12 |
| #Max. Boost Clock |
#Up to 5.0GHz |
| #Base Clock |
#4.3GHz |
| #L2 Cache |
#6MB |
| #L3 Cache |
#16MB |
| #Default TDP |
#65W |
| #AMD Configurable TDP (cTDP) |
#45-65W |
| #Processor Technology for CPU Cores |
#TSMC 4nm FinFET |
| #CPU Compute Die (CCD) Size |
#178mm² |
| #Package Die Count |
#1 |
| #Unlocked for Overclocking |
#Yes |
| #AMD EXPO™ Memory Overclocking Technology |
#Yes |
| #Precision Boost Overdrive |
#Yes |
| #Curve Optimizer Voltage Offsets |
#Yes |
| #AMD Ryzen™ Master Support |
#Yes |
| #CPU Socket |
#AM5 |
| #CPU Boost Technology |
#Precision Boost 2 |
| #Instruction Set |
#x86-64 |
| #Supported Extensions |
#AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| #Max. Operating Temperature (Tjmax) |
#95°C |
| #OS Support |
#Windows 11 – 64-Bit Edition
#Windows 10 – 64-Bit Edition
#RHEL x86 64-Bit
#Ubuntu x86 64-Bit
#Operating System (OS) support will vary by manufacturer. |
| #Connectivity |
| #Native USB 4 (40Gbps) Ports |
#2 |
| #Native USB 3.2 Gen 2 (10Gbps) Ports |
#2 |
| #Native USB 2.0 (480Mbps) Ports |
#1 |
| #PCI Express® Version |
#PCIe® 4.0 |
| #Native PCIe® Lanes (Total/Usable) |
#20 / 16 |
| #NVMe Support |
#Boot, RAID0, RAID1 |
| #System Memory Type |
#DDR5 |
| #Memory Channels |
#2 |
| #Max. Memory |
#256GB |
| #System Memory Subtype |
#UDIMM |
| #Max Memory Speed |
#2x1R DDR5-5200
#2x2R DDR5-5200
#4X1R DDR5-3600
#4x2R DDR5-3600 |
| #Graphics Capabilities |
| #Integrated Graphics |
#Yes |
| #Graphics Model |
#AMD Radeon™ 760M |
| #Graphics Core Count |
#8 |
| #Graphics Frequency |
#2800 MHz |
| #DirectX® Version |
#2.1 |
| #DisplayPort Extensions |
#HDR Metadata
#Adaptive-Sync
#UHBR10 |
| #DisplayPort Max Refresh Rates (SDR) |
#7680×4320 @ 60Hz
#3840×2160 @ 240Hz
#3440×1440 @ 360Hz
#2560×1440 @ 480Hz
#1920×1080 @ 600Hz |
| #DisplayPort Max Refresh Rates (HDR) |
#7680×4320 @ 60Hz#3840×2160 @ 240Hz
#3440×1440 @ 360Hz
#2560×1440 @ 480Hz
#1920×1080 @ 600Hz |
| #HDMI® Version |
#7680×4320 @ 60Hz#3840×2160 @ 240Hz
#3440×1440 @ 360Hz
#2560×1440 @ 480Hz
#1920×1080 @ 600Hz |
| #HDCP Version Supported |
#2.1 |
| #USB Type-C® DisplayPort™ Alternate Mode |
#2.3 |
| #Multi-Monitor Support |
#Yes |
| #Max Displays |
#4 |
| #AMD FreeSync™ |
#Yes |
| #Wireless Display |
#Miracast |
| #Max Video Encode Bandwidth (SDR) |
#1080p630 8bpc H.264
#1440p373 8bpc H.264
#2160p175 8bpc H.264
#1080p630 8bpc H.265
#1440p373 8bpc H.265
#2160p175 8bpc H.265
#4320p43 8bpc H.265
#1080p864 8/10bpc AV1
#1440p513 8/10bpc AV1
#2160p240 8/10bpc AV1
#4320p60 8/10bpc AV1 |
| #Max Video Decode Bandwidth |
#1080p60 8bpc MPEG2
#1080p60 8bpc VC1
#1080p786 8/10bpc VP9
#2160p196 8/10bpc VP9
#4320p49 8/10bpc VP9
#1080p1200 8bpc H.264
#2160p300 8bpc H.264
#4320p75 8bpc H.264
#1080p786 8/10bpc H.265
#2160p196 8/10bpc H.265
#4320p49 8/10bpc H.265
#1080p960 8/10bpc AV1
#2160p240 8/10bpc AV1
#4320p60 8/10bpc AV1 |
| #AMD SmartAccess Memory |
#Yes |
| #AI Engine Capabilities |
| #Brand Name |
#AMD Ryzen™ AI |
| #AMD Ryzen™ AI |
#Available |
| #Performance |
#Up to 16 TOPS |
| #Warranty |
#3 Years |
| Note: *** Features, Prices, and Specifications are subject to change without notice. |
